CCC Approval 1 FE 1 FX Port Fiber Optic To Ethernet 10/100/1000Mbps

Product Categories

HiOSO Technology Co., Ltd.

Contact Now

Name: CCC Approval 1 FE 1 FX Port Fiber Optic To Ethernet 101001000Mbps
Brand: Hioso
Price: 1 USD

Brand Name : Hioso

Model Number : FC830AG

Certification : CE, RoHS, CCC

Place of Origin : China, Guang dong

MOQ : 1

Price : Negotiable

Payment Terms : T/T

Supply Ability : 5000pcs/month

Delivery Time : 2-7 working days

Packaging Details : 35X25X10 cm

Product name : Fiber Media Converter

Wavelength : 850nm/1310nm/1550nm

Standard : IEEE802.3 10Base-T

Access mode : 10/100/1000Mbps

Delay : <1us

Mac : 1K

Contact Now

Fiber Media Converter 1 Fe + 1 Fx Port Gigabit Fast Ethernet Converter

Charater

10/100/1000Mbps adaptive, for the convenience of network upgrade;
Efficient built-in switching core, to implement flow control and reduce broadcast packets;
Supporting full-duplex and half-duplex transmission modes and capable of automatic
negotiation;
Supporting automatic crossing of twisted pair ports, for the convenience of system debugging
and installation; ;
Supporting FX half-duplex/full-duplex transmission modes
Supporting low-delay transmission;
Supporting transmission of extra-long packets (with the maximum length of 1600 bytes);
Extremely low power consumption (less than 2W),

Technical Specifications

Parameters	Specifications
Access mode	10/100/1000Mbps
Wavelength	850nm/1310nm/1550nm
Port	One RJ45 port: Connected to STP/UTP category-5 twisted pairs One fiber port: Multi-mode – SC (fiber size: 50,62.5/125μm) Single mode – SC fiber port (fiber size: 9/125μm) Single-fiber single-mode – SC fiber port (fiber size: 9/125 μ m)
Conversion mode	Medium conversion, storing and forwarding/straight-through
MAC address table	I K
Buffer space	1Mbit
Flow control	Full duplex state: flow control; half-duplex state: back pressure mode
Delay	<1 us
Bit error rate	<1/1000000000
MTBF	100,000 hours
LED	POWER (power), FX LINK/ACT (fiber link/action) FDX (FX full-duplex mode), TP LINK/ACT (twisted pair link/action); TP 100 (twisted pair: transmission rate of 100M);FX 100 (fiber: transmission rate of 100M) (external power)
Power	DC5V 1A (external), AC220V / DC48V
Power consumption	<2.5W

CCC Approval 1 FE 1 FX Port Fiber Optic To Ethernet 10/100/1000Mbps
